AutoGeek carries several brands of foam cannons. Pinacle, Wolfgang, Blackfire, etc. The only two (I think) that were listed for higher pressure/higher flow pressure washers was the AutoGeek and the MTM. So, which is better? I guess since this is AutoGeek's site, presumably they would say theirs is. But, they do sell both, so, what are the pluses and minuses? Note that I read reviews on "a major site" on the MTM and there were lots of good reviews, but a fair number of complaints saying it broke quickly.
AutoGeek foam cannon vs MTM foam cannon
- Thread starter Speedie6
- Start date
ClearVue18
New member
- Jan 27, 2018
- 1,091
- 0
MTM foam cannon is for mainly industrial type pressure washers with 3500 psi or higher. The autogeek cannon is more for household pressure washers
BudgetPlan1
Well-known member
- Dec 21, 2015
- 2,133
- 196
MTM PF22 works fine w 1.76gpm, 2000psi pressure washer. I think it's all in the orifice fitting employed.
View attachment 62040
- Thread starter
- #5
I don't know how I misread... I looked at all the cannons sold here. And I saw most of them were lower ratings. MTMs is high rated. But somehow, I thought I saw that the AutoGeek's was also high pressure. I must have had MTM's open in two tabs or something. My mistake. So, I guess I will get the MTM. Thanks for your input.
Breese147
New member
- Dec 28, 2014
- 452
- 0
I’ve been interested in upgrading my AG foam cannon and have heard about changing the orifice. My pressure washer is rated at 2000psi and 2.3gpm. So according to this chart the best orifice size for my pressure washer is 3.5?
Sent from my iPhone using Autogeekonline mobile app
Marc Hufnagel
Member
- Apr 5, 2011
- 787
- 0
My Pf22 works fine with a sunjoe 1./76gpm 2000psi. Works no differently when I use my 4000psi generac Nothing to that.
BudgetPlan1
Well-known member
- Dec 21, 2015
- 2,133
- 196
Looks like it.
That chart is for the nozzle orifice and not for the foamcannons. I have only access to the chart with liters and pressure in bar. I think that you are haveing the right orifice for the 2000psi 2.3gpm if it has the most common orifice 1.25mm that comes with it. For my PW that is rated to 2600psi 2.6gpm I upgraded to the 1.30mm orifice and has not tested it out yet. If your PW have a lower psi of 1600 you would get a thicker foam with the 1.1mm orifice. If you don't have specs higher than 2400psi and 2.6gpm I would not change it since the will be less thick. If you have a PW that is pulses when used the orifice is to little and if the foam is low you have a to large of orifice. My PW is just above to use the 1.30mm orifice but works with the original 1.25mm but the benefit is I get a better ratio with less prewash foam media with the larger orifice.
Hope it helps and I'm no pro but have read alot about it and was useing the 1.1mm orifice with big success with my very small nilfisk pressure wash with specs 1300psi. Before upgraded to a kärcher k7 premium plus flex pressure wash that I have now.
Hope it helps and I'm no pro but have read alot about it and was useing the 1.1mm orifice with big success with my very small nilfisk pressure wash with specs 1300psi. Before upgraded to a kärcher k7 premium plus flex pressure wash that I have now.
