Bought this pressure washer..... but it won't pull from a tank of water... Any help on what pressure washer will?

J

josher

New member
Joined
Sep 12, 2017
Messages
95
Reaction score
0
I bought this at home depot but I need a pressure washer that will pull water from my mobile tank of water rather than a running hose. I'm not familiar with pressure washers so I just bought this one based off of it's specs and the Honda GX200 motor... I do need it to be able to pull water from my 100 gallon tank. Any ideas? I spent $600 on this one and I can still return it.. https://www.homedepot.com/p/DEWALT-...-5-GPM-Gas-Pressure-Washer-DXPW3425/204663857

It should and will pull from a soap bucket, but only with the blue nozzle tip. Mine is similar and will only pull from a bucket with the black nozzle tip.

Hey Kevin thanks for the reply!! Well I guess my (noob) question is.... Should I return this and pay a little more for something that would pull better from a standing water source? As 200-300 more dollars wouldn't be too bad if it made the difference of being more efficient or better designed from pulling water from a standing tank source....? Thanks for the reply and please anyone else have some pressure washer knowledge? Wouldn't mind a few opinions as I am very stumped on what pressure washer to go with....water tank and hose reel... i'll keep searching information and asking questions

Are you going to be running a generator on your mobile setup? If so, you can run a water pump to create pressure at the pressure washer water inlet and you would not need a pressure washer that has the ability to draw water from an unpressureized source.

Thanks for the reply zmcgovern45! So I could just keep the pressure washer I have (it's still a good option in your opinion?) and then just buy a special water pump? Yes I actually just picked up my generator last night.... I will be running a Honda eu3000is for power.... Please let me know what sort of water pump would work if you're knowledgeable in that area, I would appreciate it! Also do you know what would be a nice 50ft. hose / hose reel for my setup? Mine says the hose is a 9/32" and when I research hose reels I see a lot of 1/4" and or 3/8".... what is 9/32" ? almost the same as 1/4 Thank you!

Looks like your unit uses 2.5 GPM of water, so you need a pump that can provide more than 2.5 GPM of water.

This is probably overkill for your needs as it is capable of 1500 GPH (25 GPM), but something along these lines....
https://www.homedepot.com/p/Superior-Pump-1-2-HP-Non-Submersible-Transfer-Pump-90050/206511870

Here is a smaller pump...
https://www.homedepot.com/p/Superio...Non-Submersible-Transfer-Pump-90040/206511906

Then you would need to purchase the appropriate fittings and hoses to plumb everything together from tank to pump to PW... I'm sure if you go to your hardware store and ask a knowledgeable employee about what you are trying to accomplish they can direct you.

...At the end of the day, it might just be easier to purchase a PW that can pull water from a static water source. Just depends what type of project you're up for I suppose.

Wow thanks for all the great information and quick reply! I certainly appreciate it! From the sounds of it, I think it would be pretty easy to return this HomeDepot Pressure washer I bought and opt for another one that can draw water ALREADY rather than having to piece by piece it all together..... With that being said what am I looking for in a pressure washer with the ability to draw water from a tank? What piece of hardware is it? I was obviously mistaken when I bought this one from HomeDepot and it saying AAA Triplex pump... I thought that meant it could pump the water from an external tank of water. If the Pressure washer units are too much more than 600 dollars I'll get a pump... If I can find one for $900 or less I will buy a new unit




zmcgovern45 said:
Looks like your unit uses 2.5 GPM of water, so you need a pump that can provide more than 2.5 GPM of water.

This is probably overkill for your needs as it is capable of 1500 GPH (25 GPM), but something along these lines....
https://www.homedepot.com/p/Superior-Pump-1-2-HP-Non-Submersible-Transfer-Pump-90050/206511870

Here is a smaller pump...
https://www.homedepot.com/p/Superio...Non-Submersible-Transfer-Pump-90040/206511906

Then you would need to purchase the appropriate fittings and hoses to plumb everything together from tank to pump to PW... I'm sure if you go to your hardware store and ask a knowledgeable employee about what you are trying to accomplish they can direct you.

...At the end of the day, it might just be easier to purchase a PW that can pull water from a static water source. Just depends what type of project you're up for I suppose.
Click to expand...

You need a unit with a direct drive pump that can draw water in from a static source (ie does not need a pressurized water source). Don't be mistaken if a unit says it can siphon chemicals, that is not the same. I'd recommend contacting a local pressure washer supplier other than a general hardware store, or a specialty store like pressurewashersdirect.com

Thanks again ZMC! I have found one pressure washer in particular that looks enticing to me.... it has the Honda GX200 motor.... already skid mounted... Viper pump so it should pump from a tank if I am now accurate? Seems to be a good option for only $200 more than the one I just returned. After I get this one (if i do and if you don't think it's a bad choice) I will still need to get a 50' or 100' hose + reel and a water tank (still unsure of size) What's your opinion on this unit if you don't mind me asking https://losangeles.craigslist.org/lgb/tls/d/professional-detailers-choice/6405582471.html

Your Dewalt pressure washer should be able to pull water from your tank with no problem. No water pump needed.

I have the same Honda engine with a General pump, 2700 psi @ 3gpm and I have it hooked up directly to my 65 gallon water tank with no water pump and it runs great.

A local pressure washer place hooked it up for me and they have been building rigs for detailers and pressure washing businesses for years.

So I went ahead and got a different pressure washer than the DeWault i picked up from Home Depot... I got this unit locally who has all parts on hand to repair if it ever needs fixing. Honda Gx200 motor and he also sold me a hose reel / hose and water tank.... I just got it back today so thought I'd share! I'm pretty excited to wash my van tomorrow! I still have to finish the Dynamat job as well as ad shelving / desk, and storage boxes neatly organized and I'll be golden. I think my 2 canopies will fit just fine in the rear somewhere standing neat or laying down even next to the water tank. it's a 275 gallon tank by the way.... It is a bit over kill but since I only have 40" between wheel wells (a very small area between the wheels) this tank was taller and not as wide as the other common tanks... plus I got this for half the price of one of the smaller tanks. :b

View attachment 61261View attachment 61262View attachment 61263View attachment 61264View attachment 61265
