A riding buddy of mine went on a little trip last weekend. On the way home the luggage bag that was strapped to his seat shifted and was rubbing on the saddlebag lid unbeknownst to him. By the time he discovered it, the damage was already done. Two really significant scratches and several abrasions and scuffs.

He called me and asked if I could take a look at it and give him my opinion/recommendation. My assessment was that I could get all of the smudges out by polishing and I could improve, but not not fully correct, the two major scratches. He said, "Have at it" and left the saddlebag with me.

Here is the repair process and final results in pics...

For perspective
View attachment 75334

Close ups of damage
View attachment 75335

View attachment 75336

Process:

1) Claybar
View attachment 75337

2) Wet sand the two deep scratches... 1500G followed by 3000G.
View attachment 75338

Scratch #1, Early in the process
View attachment 75339

And as far as I dared to go
View attachment 75340

Scratch #2, I got this one out nearly 100%
View attachment 75341

Scratches sanded and blended/feathered into surrounding area
View attachment 75342

3) Compounding with primary focus on sanded areas. 3" Rotary, wool pad, and Meg's 110.
View attachment 75343

View attachment 75344

4) Polishing with 3" Random Orbital and Meg's 210. First polishing cycle with a wool pad, followed by a second cycle with a yellow Griot's foam pad.
View attachment 75345

View attachment 75346

5) Wax - Meg's Ultimate Liquid hand applied.
View attachment 75347

6) Final Wipe with Meg's D115
View attachment 75348

And the results...
View attachment 75349

View attachment 75350

Very nice! The sanding pattern impressed me the most. Can tell you know what you’re doing.

Awesome job! Your riding buddy should be thrilled with the results.
