Installing HP Foam Cannon on Ryobi

[Breese147]

Ok so I just received my foam cannon but I have no idea how to hook everything up to the pressure washer HELP PLEASE!



[Breese147]

View attachment 34193View attachment 34194



[Breese147]

Also pressure washer is a electric ryobi 1700



[Breese147]

Anybody?



[af90]

The metal connector screws to the foam cannon itself. Then the end with the o ring and tabs replaces the wand portion into the gun. You should be able to insert it sideways and rotate to lock into place just like the wand. Just make sure you know which way it rotates so when you do rotate it to lock it isn't upside down.

The threaded end on the gun connects to the metal braided hose which connects to the pressure washer itself.



[Breese147]

Thanks!



[poweraid]

I got the same pressure washer I hook mine up to the quick connect fitting in end of lance like u do with the spray tips . but it's quite long .
what/which is that adapter that just goes in place where the ryobi stock lance fits in - twist fit type ?



[Breese147]

It's the Bosch adapter from Autogeek



[Breese147]

View attachment 34195 up and running just don't have time to wash the truck today.



[Breese147]

I got the same pressure washer I hook mine up to the quick connect fitting in end of lance like u do with the spray tips . but it's quite long .
what/which is that adapter that just goes in place where the ryobi stock lance fits in - twist fit type ?

It's the Bosch adapter http://www.autogeek.net/bosch-fitting.html



[af90]

Good to see! The black knob adjusts the dilution ratio so if you find it too watery or that you are going through your solution too quick adjust that. I always run mine until empty then allow some pure water to run through it to remove any soap residue.
