SunJoe SPX3000

D

Dtcjem

New member
Joined
Jan 14, 2013
Messages
48
Reaction score
0
Just a heads up.....

I recently purchased a SunJoe SPX3000 pressure washer, which I love by the way, and bought a new trigger for it to use specifically with my foam cannon. Their pressure hose connection is propriety and they will not sell them. (Just got off the phone with them) The cannon works fine on the end of the wand, but if you want a new "pistol" type trigger, it will not work.....................OR, I haven't discovered the work around yet.

Dtcjem said:
Just a heads up.....

I recently purchased a SunJoe SPX3000 pressure washer, which I love by the way, and bought a new trigger for it to use specifically with my foam cannon. Their pressure hose connection is propriety and they will not sell them. (Just got off the phone with them) The cannon works fine on the end of the wand, but if you want a new "pistol" type trigger, it will not work.....................OR, I haven't discovered the work around yet.
Click to expand...
What connection are you referring to?

I quickly looked on their website and the hose connection is M22 which is very common.

If we are talking about the same connection you would have plenty of options to get a different gun or trigger handle.

Just as an example the MTM hydro m407 gun has a female 3/8 NPT connection so you need a male 3/8 NPT quick connecter plug. Then you just need a M22 quick coupler for your hose and you're all set.

This would allow you to connect your foam cannon directly to the end of the trigger and not have a long wand in between the two.



Sent from my SM-G920V using Tapatalk

I am interested on what hose you replaced with. I have tried the M22 connection and it does not accept the high pressure hose from the machine to the gun. I called SunJoe and was told it was unique to their system and I could not purchase a fitting from the end of high pressure hose to a new screw on. Didn't consider a quick connect....DUH

Dtcjem - I have the exact same PW. I swapped out the hose and got a 50' hose. Also, put quick-connects on the hose-unit and hose-gun. YOu could do the same with another shorter gun as well. Additionally, I cut a short piece of garden hose for the water hookup and put the quick-connect on the connection between the hose and faucet.

Unit stays put. I can be using the PW in 30 seconds. there were several good articles on this set up on this forum. Try a search and see if you can find it. If not, I can try to take some pics for you.

Sure is nice to not have to drag the unit around the vehicle.

Found the threads. Thanks for leading me there! I didn't see them earlier

Wknd Dtlr said:
Dtcjem - I have the exact same PW. I swapped out the hose and got a 50' hose. Also, put quick-connects on the hose-unit and hose-gun. YOu could do the same with another shorter gun as well. Additionally, I cut a short piece of garden hose for the water hookup and put the quick-connect on the connection between the hose and faucet.

Unit stays put. I can be using the PW in 30 seconds. there were several good articles on this set up on this forum. Try a search and see if you can find it. If not, I can try to take some pics for you.

Sure is nice to not have to drag the unit around the vehicle.
Click to expand...
Basically what I did to my greenworks. 50' flexzilla, 6' inlet garden hose, quick couplers all around and a pretty sweet mtm hydro gun with mosmatic wand. It stays put and takes no time to set up. I'll have to start a thread when it's totally finished. Waiting on a swivel connector so my hose can spin freely under pressure.

Sent from my SM-G920V using Tapatalk

Dtcjem said:
Found the threads. Thanks for leading me there! I didn't see them earlier
Click to expand...
Feel free to ask any questions you need. I've researched couplers, connectors, and pressure washer stuff until I couldn't take it any more lol!

Sent from my SM-G920V using Tapatalk

yg1829 said:
Waiting on a swivel connector so my hose can spin freely under pressure.

Sent from my SM-G920V using Tapatalk
Click to expand...

Which one are you getting? The coupler to my gun rotates a little but nearly as well as I would like.

Wknd Dtlr said:
Which one are you getting? The coupler to my gun rotates a little but nearly as well as I would like.
Click to expand...
I ended up getting the general pump brand in stainless steel from northern tool.



Sent from my SM-G920V using Tapatalk

brw71585 said:
I bought a mosmatic swivel and its the best thing
Click to expand...
Good call on the mosmatic. The quality of their stuff is really good. I love my mosmatic wand.

Sent from my SM-G920V using Tapatalk

I just bought a Karcher K2 Plus last week. Hope, it works fine..

Headed to Tractor Supply now. Let you know what they have for hose. Their website shows the Simpson 50' in stock. :fingers crossed:

I was able to pick up a 50' Simpson hose for under $50.00. Haven't been able to try it yet but confident it will be perfect. Now just need to pick up some Quick connections.


Sent from my iPhone using Autogeekonline mobile app

I also just purchased the same model. I currently use a gas powered PW with a Kranzle fitting. I was hoping to start using the electric one for washing cars mainly due to noise. From what you guys are saying, I can't use the setup I have with the Sun Joe? I was hoping I can just move the Kranzle fitting to my Sun Joe and attach it with the foam cannon. If not, anything else I need to purchase to start using this?

I recently just purchased a SPX3000 and MTM M470 spray gun as well.. can someone link me to the adapters I need to fit the spray gun into the pressure washer's hose, or a different hose I need to get?

Midnite8 said:
I recently just purchased a SPX3000 and MTM M470 spray gun as well.. can someone link me to the adapters I need to fit the spray gun into the pressure washer's hose, or a different hose I need to get?
Click to expand...

1 - 3/8 Female Coupler
1 - 3/8 Male Plug
2 - 1/4 Male Quick Disconnect Coupler ( One for gun and one for Wand if it does not come with it)
1 - 1/4 Female Plug
1 - 3/8 Female Quick Disconnect Plug
1 - Mosmatic wand or any wand of choice (If you want wand then dm so I can point you in direction to get it)
1 - Mosmatic 3/8M x 3/8F Gun Swivel (DM so I can show I can point in direction to get it
1 - Pressure Washer 22m-14 x 22m-15 coupler plug ( If you use the hose provided by Sunjoe, if you use separate hose then do not need this)
1 - M22 female x 3/8 male

View attachment 55585View attachment 55586
