The Karcher X Series...
About 4 years ago I bought a Karcher X Series (K5.540) , 2000 PSI, 1.4 GPM unit (product link) to be used for car washing. This was my first electric pressure washer, and I figured I would buy the "top of the line" expensive model so I wouldn't have any regrets later. Well, I screwed up....
The Karcher unit was... fine. I mean it sprayed water at higher pressure, so I suppose it functioned, but after fighting with it for so long, that is about the only good thing I can say about it. The hose was a stiff, cheap product that would never lay flat. It always tried to retain the coiled up shape even when it was uncoiled. Thanks to Karcher's unique connections, the only option that I had found to replace the hose was with another Karcher hose... so I was stuck with it. The spray gun and wand were also cheap, flimsy products. The variable pressure wand is a nice idea, however I only utilized the widest fan setting, so the variable settings were not needed by any means. Again, thanks to the Karcher connections, I was also stuck with this gun. Due to these proprietary connections, I also had to purchase an adapter to allow me to use my foam cannons with this sprayer. The attachment on the PW body to hold the gun while it was being stored fell off regularly, as did the hook to hang the extension cord on. This was an issue from day one. Very cheaply made, poorly designed pieces. In the end, it was the power cord that gave up on me, and instead of spending $20 to fix it, I sold the entire unit for $30 on craigslist. I just wanted it gone. Time to start over.
My inspiration...
I had watched some videos by Matt on Obsessed Garage where he went over a lot of the research he had done on pressure washer fittings, wands, guns, hoses, etc. and I became intrigued. I knew my next setup needed to incorporate some higher end components (hose and gun, specifically) so I would not have the same complaints as I did with the Karcher unit. I have always been a fan of the MTM Foam Cannons, so I spent some time on their site and the OG site checking out fittings, hoses, and guns. I liked what I saw so I decided to get to work....
The Cheap Ryobi...
I went to my local home depot and picked up the cheapest pressure washer they had. A 1600 PSI, 1.2 GPM Ryobi unit (product link). This unit retails for $119, but I had a coupon and got it for $101 + tax. I knew I would not be using the included hose or gun, I just needed the unit itself. This little thing is a great, compact size. It is very lightweight and easy to move around, unlike the overweight karcher unit I had previously.
Upgrading the Ryobi...
The output of the Ryobi PW is an M22 male thread where the supplied Ryobi hose would typically connect. Since I would not be using this hose, I needed to convert the M22 thread to a 3/8" coupler as that is a common size found on most higher end hoses. From there I needed the use the appropriate fittings to connect the hose to the pressure washer, and the hose to my new MTM SG-28 Spray Gun. A 1/4" coupler was added to the output of the spray gun to allow for easy changes between spray nozzles and foam cannons. The following photo shows the full layout of parts. Click here to download the PDF with links to all parts and a 2nd option to upgrade your hose and gun.
Some of the parts once they arrived....
Just put the new setup to the test today, and I am very pleased!!!
(Used with MTM Hydro PF22 Foam Cannon and Optimum Car Wash. 40* Nozzle used for rinsing)
Initial Impressions of the New Setup...
Man is it nice to have a 50' hose! Man is it nice to have a hose that doesn't get twisted and tangled! Man is it nice to have a PW that doesn't fall over!
Alright, so I do not have a hose reel on this new unit. This means I have to connect and disconnect the high pressure hose each time I use it which adds a couple of minutes to my job, but I sort of prefer it this way. The PW unit remains very compact and lightweight without the hose reel. I simply roll up my hose and hang it on a hook inside my garage above the pressure washer, just like I do with my garden hose. My foam lance and spray gun have spots on my pegboard.
The SG-28 spray gun is very nice. While it is still a completely plastic body, the build quality is much better than the Karcher gun. It just feels sturdy. There isn't a bunch of play in the trigger.
The MTM nozzles with the appropriately selected orifice size are fantastic!! It feels like this 1600 PSI unit has a much stronger stream than the 2000 PSI karcher did. I think the Karcher spray wand was the limiting factor there.
The connectors and fittings are very solid. No leaks, and no issues connecting or disconnecting anything during setup, use, and tear down.
At the end of the day, I spent less money on this new setup than I did on the Karcher several years ago. I feel the Ryobi (or other similar inexpensive unit) with the upgraded components is absolutely the right way to go for consumer setups! So far I'm very happy with my switch.
